CCS 600W HD-LITE Windows 7 Navigational Echo Sounder High Accuracy Lightweight Cost-effective
Key Attributes
Brand Name:
THUNDSEA
Model Number:
HD-LITE
Place of Origin:
Qingdao
Certification:
CCS
Minimum Order Quantity:
one set
Supply Ability:
30 set per month
Delivery Time:
15 Days
Payment Terms:
L/C, T/T
Standard Packaging:
carton box
Product Summary
CCS 600W HD-LITE Windows 7 Navigational Echo Sounder High Accuracy Lightweight Cost-effective Features Highest-end industrial computer platform, Windows 7 operating system used. Built-in HiMAX measurement software, a perfect combination of control, navigation, data acquisition and post-processing. ...
Product Custom Attributes
Highlight
HD-LITE portable echo sounder
,Windows 7 marine echo sounder
,200m boat echo sounder
Working Frequency:
200kHz
Transmitting Power:
600W
Range:
0.15m~200m
Accuracy:
±10mm＋0.1%h,resolving Power:1cm
Draft Range:
0m~30m
Sound Speed Range:
1370~1700m/s,resolving Power 1m/s
CPU Main Frequency:
1.92GHz,dual Frequency
Memory:
2GB
Maximum Rate Of Water Depth Sampling:
30Hz
Hard Disk:
32GB SSD Solid Srare Hard Disk
Display:
15 Inches,1280*1024@60Hz Resolution
External Port:
3*RS-232,3*USB
VGA:
A VGA Interface For Split-screen Display
Power Supply:
10~30V Wide Voltage/AC
Average Power Consumption:
Less Than 40W
Working Temperature:
－20℃~70℃
Outline Size:
440×320×110mm
Weight:
5.8kg
Bluetooth Communicator:
Built-in
Product Description
CCS 600W HD-LITE Windows 7 Navigational Echo Sounder High Accuracy Lightweight Cost-effective
Features
Highest-end industrial computer platform, Windows 7 operating system used.
Built-in HiMAX measurement software, a perfect combination of control, navigation, data acquisition and post-processing.
Automatic control of transmitting power, gain and signal threshold to realize automation of sounding operation
Built-in Bluetooth module to achieve no cable GNSS communication
Overlap of water depth analog and digital signal gets a quick and accurate water depth interpretation.
15-inch high brightness LCD, weight only 5.8 kg
Technical Specifications
| Working frequency | 200kHz |
| Transmitting power | 600W |
| Range | 0.15m~200m |
| Accuracy | ±10mm＋0.1%h,resolving power:1cm |
| Draft range | 0m~30m |
| Sound Speed Range | 1370~1700m/s,resolving power 1m/s |
| CPU main frequency | 1.92GHz,dual frequency |
| Memory | 2GB |
| Maximum rate of water depth sampling | 30Hz |
| Hard disk | 32GB SSD Solid Srare Hard Disk |
| Display | 15 inches,1280*1024@60Hz resolution |
| External port | 3*RS-232,3*USB |
| VGA | A VGA interface for split-screen display |
| Power Supply | 10~30V Wide Voltage/AC |
| Average power consumption | Less than 40W |
| Working temperature | －20℃~70℃ |
| Outline size | 440×320×110mm |
| Weight | 5.8kg |
| Bluetooth Communicator | Built-in |
