High Accuracy TDF72IMU0 Fiber Optic Inertial Unit Low Power Consumption

Large Image : High Accuracy TDF72IMU0 Fiber Optic Inertial Unit Low Power Consumption

Product Details:

Place of Origin:	China
Brand Name:	NAVI OPTICS
Certification:	CCS
Model Number:	TDF72IMU0
Document:	TDF72IMU0 Fiber Optic Inert...it.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	one set
Packaging Details:	carton box
Payment Terms:	T/T,L/C

Contact Now

High Accuracy TDF72IMU0 Fiber Optic Inertial Unit Low Power Consumption

Description

Zero Bias Stability (100s):	0.01°/h	Zero Bias Stability (10s):	0.03°/h
Variable Temperature Zero Bias Stability:	0.05°/h	Full Temperature Scale Factor:	≤150ppm
Random Walk Coefficient:	0.002°/h	Input Range:	400°/s
Highlight:	fiber optic inertial measurement unit , low power IMU sensor , high accuracy inertial unit

High Accuracy TDF72IMU0 Fiber Optic Inertial Unit Low Power Consumption

♦ Overview

This type of fiber optic inertial unit contains eight points of vibration reduction, which can meet the application scenarios of large impact and large vibration. It has the advantages of small size, light weight, low power consumption, and high accuracy. It has the dynamic measurement function of carrier angular and linear motion information for the use of small volume and high-precision inertial unit equipment in water/torpedo weapons, as well as land, airborne, and missile weapon platforms.

♦ Performance

Project	Contents	Index	Notes
Performance indicators of gyroscope
Zero bias indicator	Zero bias stability (100s)	0.01°/h
	Zero bias stability (10s)	0.03°/h
	Variable temperature zero bias stability	0.05°/h
Scale Factor	Full temperature scale factor	≤150ppm
Other indicators	Random walk coefficient	0.002°/h
Other indicators	Input range	400°/s
Performance indicators of accelerometer
Deviation index	Deviation monthly comprehensive error	20μg
Zero bias indicator	Zero bias temperature sensitivity	20μg/℃
Scale Factor	Scale factor monthly comprehensive error	20ppm
Scale Factor	Scale factor temperature sensitivity	20ppm/℃
Range indicator	Input range	±20g
Whole machine characteristics
Environmental performance indicators	Operation temperature	-40℃～60℃
Environmental performance indicators	Storage temperature	-45℃～70℃
General requirements	Power supply	18～36V(DC)
General requirements	Stable power consumption	≤15W	Startup power consumption ≤ 25W

♦ Electrical Interfaces

Pin	Connectivity	Signal name	Signal characteristics
1,2	External power supply	PCS power supply positive	24V
3,4	External power supply	PCS power supply ground	Power Ground
5	200Hz signal output	IMU_TX1+	IMU data output positive
6	200Hz signal output	IMU_TX1-	IMU data output negative
9	Synchronization signal	IMU_SYN+	IMU synchronization signal positive
10	Synchronization signal	IMU_SYN-	IMU synchronization signal negative

♦ Structural appearance and dimensions
