Control Grade TDFG70S Compact High Accuracy Fiber Optic Gyroscope (FOG) for Precision Navigation
Key Attributes
Brand Name:
NAVI OPTICS
Model Number:
TDFG70S
Place of Origin:
China
Certification:
CCS
Minimum Order Quantity:
one set
Supply Ability:
30 set per month
Delivery Time:
15days
Standard Packaging:
carton box
Product Summary
Control Grade TDFG70S Fiber Optic Gyroscope Compact Product Overview The TDFG70S Fiber Optic Gyroscope is an advanced angular velocity sensing device that operates on the Sagnac effect in optical systems. Featuring sophisticated all-digital closed-loop control systems, it provides real-time angular ...
Product Custom Attributes
Highlight
Compact Fiber Optic Gyroscope
,Control Grade Fiber Optic Gyroscope
Dynamic Range:
≥±400°/s
Bias In-run:
＜1°/h
Accuracy（10sec）:
0.05°/h~0.03°/h
ARW（Angular Random Walk:
＜0.005°/√hr,1σ
Vibration Screening:
20~2000Hz，6.06g
Bandwidth:
＞200Hz
Weight:
≤300g
Dimensions:
70mm×70mm×30mm
Product Description
Control Grade TDFG70S Fiber Optic Gyroscope Compact
Product Overview
The TDFG70S Fiber Optic Gyroscope is an advanced angular velocity sensing device that operates on the Sagnac effect in optical systems. Featuring sophisticated all-digital closed-loop control systems, it provides real-time angular velocity measurements of moving platforms through high-speed serial interfaces with sampling rates exceeding 4 kHz.
Configurations & Capabilities
Available in single-axis, dual-axis, and three-axis configurations, this product line enables multi-axis synchronization for comprehensive dynamic motion analysis. Dual and three-axis variants achieve simultaneous orthogonal-axis detection through integrated designs featuring shared optical components and electronic processing units, ensuring precise measurement coherence across all axes.
Applications
Ideal for stabilization and control equipment for guided weapons, tactical missiles, torpedoes, attitude control systems, and medium to high-end industrial equipment requiring precise motion sensing.
Key Characteristics
- All-solid-state design with no moving parts
- Instant-on capability with digital output for easy computer integration
- Compact size, lightweight construction, and flexible design options
- Low noise, low power consumption, and cost-effective operation
- High reliability and extended operational lifespan
Technical Specifications
| Performance Parameter | Specification |
|---|---|
| Dynamic Range | ≥±400°/s |
| Bias In-Run | <1°/h |
| Accuracy (10sec) | 0.05°/h ~ 0.03°/h |
| Angular Random Walk (1σ) | <0.005°/√hr |
| Vibration Screening | 20~2000Hz, 6.06g |
| Bandwidth | >200Hz |
| Turn On Time | 10s |
| Output Signal Format | RS-422 |
| Output Signal Update Rate | 500Hz ~ 4000Hz |
| Output Signal Baud Rate | 115200bps ~ 921600bps |
| Operating Temperature | -40℃ ~ +70℃ |
| Storage Temperature | -55℃ ~ +85℃ |
| Power Supply | 5V |
| Connector | J30J-15TJL |
| Power Consumption | ≤3W |
| MTBF (per MIL-HDBK-217-F) | >150,000hr |
| Weight | ≤300g |
| Dimensions | 70mm * 70mm * 30mm |
